An induction cooktop cannot run all of its elements at their rated power at once, and the manufacturer's own spec sheet shows it. Bosch's spec sheet for the 800 Series 30-inch NIT8069UC rates the four elements at 1,400, 2,200, 2,600 and 1,400 watts, which adds to 7,600 watts, and rates the appliance at 7,200 watts on a 30-amp, 208 to 240-volt circuit. In boost the four are rated 2,200, 3,700, 3,700 and 2,200 watts, or 11,800 watts, which is 1.64 times what the cooktop is rated to draw. The condition that decides how often this matters is how many pans go on at once: two zones at full power is inside the budget, four is not.
The elements add up to more than the cooktop
The figure to compare is the per-element wattage against the appliance total on the same sheet, because the total is the one the circuit sees. Bosch's published numbers for the NIT8069UC:
Scroll sideways to see the full table →
| Element | Diameter | Rated | In boost |
|---|---|---|---|
| Front left | 6 inches | 1,400 W | 2,200 W |
| Back left | 9 inches | 2,200 W | 3,700 W |
| Back right | 11 inches | 2,600 W | 3,700 W |
| Front right | 6 inches | 1,400 W | 2,200 W |
Example, on Bosch's figures: the appliance total of 7,200 watts divided by 240 volts is 30 amps, which is exactly the circuit breaker rating Bosch prints. The four elements at their rated power come to 7,600 watts, 400 watts above the total. All four in boost come to 11,800 watts, 4,600 watts above it. Bosch states that all burners have a booster; the sheet does not state that all of them can use it at the same time. The shortfall is made up by sharing, and sharing is silent: the control panel keeps showing the setting that was chosen.
That is the mechanism behind the complaint that a cooktop "lost power" mid-recipe. Nothing failed. The budget ran out, and the display did not say so.
The DOE test heats water in a standard vessel
Federal energy figures for cooktops come from Appendix I1 to Subpart B of 10 CFR Part 430, the uniform test method for conventional cooking products. It does not cook food. Each cooking zone is tested with a vessel meeting Section 5.6.1 and Annex B of IEC 60350-2, filled with water starting at 77 degrees Fahrenheit (25 plus or minus 0.5 degrees Celsius), and the annual figure is built from 418 cooking cycles per year and reported as integrated annual energy consumption in kilowatt-hours per year.
Two consequences follow from reading that procedure. The test vessel is flat, standard and sized to the zone, so it flatters a cooktop the way a warped or undersized pan will not; and a zone the appendix classes as a specialty cooking zone, such as one shaped only for non-circular cookware, is not tested at all. An efficiency number is therefore a statement about a standard pot on a standard zone, which is why the pans themselves decide what the kitchen actually gets.
Induction is inside the federal definition, unlike a countertop box
10 CFR 430.2 defines a conventional cooking top as a household cooking appliance with a horizontal surface containing one or more surface units that use a gas flame, electric resistance heating, or electric inductive heating. Induction is covered by the same definition, the same test procedure and the same reporting as a coil or a radiant top. The same section excludes portable or countertop ovens that use electric resistance heating and are designed for an electrical supply of approximately 120 volts, which is why a countertop fryer's capacity claim has no federal test behind it and a cooktop's energy figure does.
The circuit is part of the price
A 30-amp, 240-volt circuit is not a small addition to a panel, and it competes with everything else a household wants to add, including a car charger in the garage. Bosch's spec sheet states 208 to 240 volts, 60 hertz, a 30-amp circuit breaker, no plug, and a 37-inch power cord, with a required cutout of 4 1/8 by 28 7/8 by 20 inches and a net weight of 41 pounds. Those five figures, not the feature names, decide whether an installation is a swap or a rewire.
Before you buy an induction cooktop
- The per-element wattage and the boost wattage for every zone, next to the appliance's total rated watts on the same spec sheet.
- The circuit breaker rating and voltage range the manufacturer prints, and confirmation that the panel has that circuit free.
- The required cutout in inches and the appliance's net weight, from the spec sheet rather than the product listing.
- A statement of which zones share power, and what the display shows while power is being shared.
- The zone diameters in inches, compared against the base diameter of the pans that will sit on them.
- The integrated annual energy consumption in kilowatt-hours per year, which is measured with an IEC 60350-2 test vessel and water at 77 degrees Fahrenheit.
- The service and parts documentation for the glass surface and the touch control, which are the two parts that fail as a unit.
